Product Description

8” Recessed Impeller High Head Sewage Pump

KEEN PUMP “KH” Series pumps are designed for demanding wastewater, municipal sewage treatment plants, storm water, industrial, commercial and a wide range of water-handling applications.

“KH” Series pumps feature a self-contained cooling jacket system, circulating impeller, heat exchanger plate and liquid refrigerant with a high boiling point (195º C). Standard construction allows for submersible and dry pit installations.

“KH” pumps are equipped with high-efficiency, inverter-duty rated, Class H insulation motors. Electrical features include fully automatic alarm protection system and liquid level control system, protecting the motor from water, oil, phase loss, overheating and grounding.

CAPABILITIES:

  • Flow to 6300 GPM
  • Heads to 330 Feet
  • Horsepower: 500 HP
  • Voltage/Phase Options:460, 3 Phase
  • Discharge Connections: 8” ANSI 150 Lb., Horizontal Flange
  • Motor Speeds: 1750 rpm
  • Solids Handling: 3.5”
  • Impeller: Balanced, Vaned-Enclosed
  • Motor Serice Factor 1.15

Additional Details

No additional technical data available at this time.
