KEEN PUMP “KH” Series pumps are designed for demanding wastewater, municipal sewage treatment plants, storm water, industrial, commercial and a wide range of water-handling applications.
“KH” Series pumps feature a self-contained cooling jacket system, circulating impeller, heat exhanger plate and liquid refrigerant with a high boiling point (195º C). Standard construction allows for submersible and dry pit installations.
“KH” pumps are equipped with high-efficiency, inverter-duty rated, Class H insulation motors. Electrical features include fully automatic alarm protection system and liquid level control system, protecting the motor from water, oil, phase loss, overheating and grounding.
CAPABILITIES:
Flows to 12,500 GPM
Heads to 131 Feet
Horsepower: 275 HP
Voltage/Phase Options: 460, 3 Phase
Discharge Connections: 16” ANSI 150 Lb., Horizontal Flange
Motor Speeds: 710 RPM
Solids Handling: 6”
Impeller: Balanced, Vaned – Enclosed
Motor Serice Factor: 1.20
